Huawei eKit-AP160 Wall Plate Access Point

  • The Huawei eKit-AP160 Wall Plate Access Point is a versatile and compact networking
  • solution suited for locations with limited space, such as hotels, hospitals, and small businesses.
  • This wall-mounted access point blends practicality and beauty
  • blending perfectly into any indoor environment while offering reliable wireless communication.

Original price was: 4.200,00 EGP.Current price is: 3.600,00 EGP.

Added to wishlistRemoved from wishlist 0

Huawei eKit-AP160

AP160 is a Wi-Fi 6 (802.11ax) wall plate access point. It can simultaneously provide services on 2.4 GHz

Huawei eKit-AP362 Access Point :

AP160 is a Wi Fi 6 80211ax wall plate access point It can simultaneously provide services on 24 GHz

the best wall plate

The Huawei eKit-AP160 Wall Plate Access Point is a versatile and compact networking

solution suited for locations with limited space, such as hotels, hospitals, and small businesses.

This wall-mounted access point blends practicality and beauty

blending perfectly into any indoor environment while offering reliable wireless communication.

The eKit-AP160 operates on both the 2.4GHz and 5GHz frequency bands

and provides a consistent wireless throughput of up to 1.167 Gbps

allowing customers to enjoy high-speed internet access for a variety of applications

like as video streaming, online conferences, and regular web surfing.

One of the eKit-AP160’s primary characteristics is dual-band operation

which improves performance by dividing network traffic across two different bands.

This dual-band functionality is especially useful in high-density areas

where several devices may be connected simultaneously.

The access point features MU-MIMO (Multi-User, several Input, Multiple Output) technology

which allows it to communicate with several users simultaneously without compromising performance.

This is critical in busy environments, such as conference rooms or crowded halls

where many people may be using bandwidth for different purposes.

The Huawei eKit-AP160’s Power over Ethernet (PoE) functionality makes installation simple.

This feature allows the access point to accept both power and data over a single Ethernet cable

making deployment easier and reducing the need for extra power outlets.

The wall plate design optimizes space and makes the gadget less invasive.

AP160 is a Wi Fi 6 80211ax wall plate access point It can simultaneously provide services on 24 GHz

the best wall plate

Huawei :

Huawei is a multinational technology company

Made important contributions to the communications industry.

Huawei, which was founded in 1987, has evolved

To become one of the largest providers of communications equipment and consumer goods in the world.

Huawei has created a variety of products and services to meet consumer demands

Companies and governments, with a focus on innovation and cutting-edge technology.

Huawei offers a comprehensive and diverse range of products renowned for their quality and performance

From smartphones and tablets to networking equipment and cloud computing solutions.

Huawei smartphones have gained global popularity

Thanks to its innovative features, beautiful aesthetics, and affordable prices.

The company’s dedication to research and development

has led to develop game-changing technology

such as artificial intelligence computers,

Leica engineered cameras and long-lasting batteries.

AP160 is a Wi Fi 6 80211ax wall plate access point It can simultaneously provide services on 24 GHz

the best wall plate

You can also view a similar version from Huawei

Specification: Huawei eKit-AP160 Wall Plate Access Point

Brand

Huawei

Model

AP160

Installation Type

Junction Box

Dimensions without packaging (H x W x D) [mm(in.)]

86 mm x 42.5 mm x 86 mm (3.39 in. x 1.76 in. x 3.39 in.)

Dimensions with packaging (H x W x D)

[mm(in.)] 117 mm x 73 mm x 98 mm (4.61 in. x 2.87 in. x 3.86 in.)

Weight without packaging [kg(lb)]

0.14 kg (0.39 lb)

Weight with packaging [kg(lb)]

0.24 kg (0.53 lb)

Maximum power consumption [W]

9.1

Power supply mode

PoE

Input voltage range [V]

PoE: 802.3af

Service port surge protection [kV]

PoE port: Common mode (8 wires to ground): 4 kV (1.2/50 us, 42 ohms), criterion C

Maximum number of physical ports on the entire device

GE (RJ45) x 2, 10M/100M/1000M auto-sensing

Long-term operating temperature [°C(°F)]

–10°C to +50°C (14°F to 122°F) (If the altitude is in the range of 1800 m to 5000 m, the temperature decreases by 1°C or 1.8°F every time the altitude increases by 300 m.)

Storage temperature [°C(°F)]

–40°C to +70°C (–40°F to +158°F)

Long-term operating relative humidity [RH]

5% RH to 95% RH

Long-term operating altitude [m(ft.)]

–60 m to +5000 m (–196.85 ft to +16404.20 ft)

Atmospheric pressure [kPa]

53 kPa – 106 kPa ETSI 300 019-2-3

Ground

floating ground

Radio number

2

Operating frequency band

• 2.4GHz • 5GHz

Radio interface

Built-in smart antennas

Antenna gain

2.4G: 3 dBi/chain (peak) 3 dBi (combined gain) 5G: 2 dBi/chain (peak value) 1 dBi (combined gain)

Maximum transmit power

2.4G: 17 dBm/chain 20 dBm (combined power) 5G: 17 dBm/chain 20 dBm (combined power)

Single-frequency transmit power [dBm]

2.4G: 0 dBm~17 dBm /chain 5G: 0 dBm~17 dBm /chain
