Huawei eKit-S220S-24P4J-24 Switch

  • The Huawei eKit-S220S-24P4J-24 Switch is a high-performance networking solution
  • designed specifically for businesses wishing to improve their network infrastructure
  • with dependable and efficient switching capabilities.
  • This Layer 2 controlled switch is intended to fulfill the needs of modern networks
  • with advanced features that ensure peak performance and security.

Original price was: 15.200,00 EGP.Current price is: 14.300,00 EGP.

Added to wishlistRemoved from wishlist 0

Huawei eKit-S220S-24P4J-24

eKit-S220S-24P4J-24 10/100/1000BASE-T PoE+ ports,4 x 2.5GE SFP ports | Packet forwarding rate: 51 Mpps | Switching capacity: 68 Gbit/s

Huawei eKit-S220S-24P4J-24 Switch :

eKit S220S 24P4J 24 101001000BASE T PoE+ ports4 x 25GE SFP ports | Packet forwarding rate 51 Mpps | Switching capacity 68 Gbits

the best Huawei Switch

The Huawei eKit-S220S-24P4J-24 Switch is a high-performance networking solution

designed specifically for businesses wishing to improve their network infrastructure

with dependable and efficient switching capabilities.

This Layer 2 controlled switch is intended to fulfill the needs of modern networks

with advanced features that ensure peak performance and security.

With 24 Gigabit Ethernet ports, the eKit-S220S-24P4J-24 provides ample bandwidth

for connecting multiple devices, making it an excellent solution

for small to medium-sized organizations or branch offices that require high-speed data transfer.

One of this switch’s standout characteristics is its Power over Ethernet (PoE) functionality

which allows it to provide both power and data over the same Ethernet line.

The switch supports up to four PoE ports, providing a total PoE budget sufficient

to power a variety of devices like IP cameras, VoIP phones, and wireless access points.

This feature not only simplifies installation by eliminating the need for additional power sources

but it also increases network flexibility, allowing organizations

to deploy devices in areas without easy access to power outlets.

The Huawei eKit-S220S-24P4J-24 includes extensive administration

and monitoring functions to assist network administrators in ensuring optimal performance and security.

It supports VLAN (Virtual Local Area Network) settings

which enable network traffic segmentation for increased security and performance.

This functionality is critical for avoiding illegal access and efficiently managing bandwidth

across multiple departments or services within a business.

eKit S220S 24P4J 24 101001000BASE T PoE+ ports4 x 25GE SFP ports | Packet forwarding rate 51 Mpps | Switching capacity 68 Gbits

the best Huawei Switch

Huawei :

Huawei is a multinational technology company

Made important contributions to the communications industry.

Huawei, which was founded in 1987, has evolved

To become one of the largest providers of communications equipment and consumer goods in the world.

Huawei has created a variety of products and services to meet consumer demands

Companies and governments, with a focus on innovation and cutting-edge technology.

Huawei offers a comprehensive and diverse range of products renowned for their quality and performance

From smartphones and tablets to networking equipment and cloud computing solutions.

Huawei smartphones have gained global popularity

Thanks to its innovative features, beautiful aesthetics, and affordable prices.

The company’s dedication to research and development

has led to develop game-changing technology

such as artificial intelligence computers,

Leica engineered cameras and long-lasting batteries.

eKit S220S 24P4J 24 101001000BASE T PoE+ ports4 x 25GE SFP ports | Packet forwarding rate 51 Mpps | Switching capacity 68 Gbits

the best Huawei Switch

You can also view a similar version from Huawei

Specification: Huawei eKit-S220S-24P4J-24 Switch

Brand

Huawei

Model

S220S-24P4J

Remarks

If the upper-level circuit breaker for a device is also connected to many other devices, a C32 or above circuit breaker needs to be used. If the upper-level circuit breaker for a device is connected only to this device, a C25 or below circuit breaker can be used.

Certification

EMC certification Safety certification Manufacturing certification

Static power consumption [W]

18.74

Dimensions without packaging (H x W x D) [mm(in.)]

Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442 mm x 220 mm (1.72 in. x 17.40 in. x 8.66 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442 mm x 227 mm (1.72 in. x 17.40 in. x 8.94 in.)

Dimensions with packaging (H x W x D)

[mm(in.)] 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.)

Chassis height [U]

1

Installation type

Rack mounting,Desk mounting,Wall mounting

Weight without packaging [kg(lb)]

2.8 kg (6.17 lb)

Weight with packaging [kg(lb)]

3.71 kg (8.18 lb)

Typical power consumption [W]

33.32

Maximum power consumption [W]

– Without PoE: 38.58 W – Full PoE load: 482.55 W (PoE: 400 W)

Maximum heat dissipation [BTU/hour]

– Without PoE: 131.63 – Full PoE load: 1646.51

MTBF [years]

48.77

MTTR [hours]

2

Availability

> 0.99999

Noise at normal temperature (acoustic power) [dB(A)]

52.8

Noise at high temperature (acoustic power) [dB(A)]

58.6

Noise at normal temperature (acoustic pressure) [dB(A)]

40.1

Number of power slots

0

Number of fans modules

2

Maximum number of physical ports on the entire device

28

Maximum number of 2.5GE ports

4

Maximum number of GE ports

28

Maximum number of FE ports

28

Long-term operating temperature [°C(°F)]

–5°C to +45°C (23°F to 113°F) at an altitude of 0 to 1800 m (0 to 5905.44 ft.)

Restriction on the operating temperature variation rate [°C(°F)]

When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F).

Storage temperature [°C(°F)]

–40°C to +70°C (–40°F to +158°F)

Long-term operating relative humidity [RH]

5% RH to 95% RH (non-condensing)

Long-term operating altitude [m(ft.)]

0–5000 m (0–16404 ft.)

Storage altitude [m(ft.)]

0-5000 m (0-16404 ft.)

Power supply mode

AC built-in

Rated input voltage [V]

– AC input: 100 V AC to 240 V AC, 50/60 Hz – High-voltage DC input: 240 V DC

Input voltage range [V]

– AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz – High-voltage DC input: 190 V DC to 290 V DC

Maximum input current [A]

6 A

Power supply surge protection [kV]

Differential mode: ±6 kV; common mode: ±6 kV

Ingress protection level (dustproof/waterproof)

IP20

Types of fans

Built-in

Heat dissipation mode

Air cooling for heat dissipation, intelligent fan speed adjustment

Airflow direction

Air intake from left and front, air exhaustion from right

PoE

Supported

100% power consumption [W]

33.92

Maximum PoE power consumption [W]

400

PoE+ power interfaces

24

Full load PoE power consumption 30W (802.3at)

13

Full load PoE power consumption 15.4W (802.3af)

24
