Tenda TEF1110P-8-63W Desktop Switch

  • Supports desktop and wall-mounting
  • Support two modes of Default,Extend
  • Single port output power 30W,maximum output power 58W
  • 8×PoE+ 10/100Mbps RJ45 ports,2×10/100Mbps RJ45 ports

Original price was: 2.210,00 EGP.Current price is: 2.060,00 EGP.

Added to wishlistRemoved from wishlist 0

Tenda TEF1110P-8-63W

TEF1110P-8-63W 10-Port 10/100M Desktop Switch with 8-Port PoE

Tenda TEF1110P-8-63W Desktop Switch :

TEF1110P 8 63W 10 Port 10100M Desktop Switch with 8 Port PoE

the best Desktop Switch

The Tenda TEF1110P-8-63W Desktop Switch is a high-performance networking

device ideal for small to medium-sized networks.

This unmanaged switch has ten ports, including eight Power over Ethernet (PoE) connectors

making it perfect for connecting IP cameras, VoIP phones, wireless access points,

and other conventional network devices.

One of the TEF1110P-8-63W’s standout characteristics is its PoE functionality,

which enables it to supply both power and data over the same Ethernet connection.

This feature makes installation easier by decreasing the need for additional power outlets.

The switch meets IEEE 802.3at/af standards, with a maximum power output of 30 watts per PoE port

and a PoE budget of 58 watts for all ports combined.

The TEF1110P-8-63W operates at speeds of 10/100 Mbps, ensuring dependable

data transmission for routine networking operations.

It also contains two dedicated uplink ports, allowing for easy network expansion

by connecting to other switches or routers.

This versatility is especially useful in contexts that require reliable communication for a variety of devices.

The Tenda TEF1110P-8-63W was created with durability and efficiency in mind.

It has 6kV lightning protection, which protects connected equipment from power surges

and electrical interference, making it appropriate for indoor and outdoor applications.

The switch’s fanless design assures silent operation, making it ideal

for noise-sensitive situations like offices or conference rooms.

TEF1110P 8 63W 10 Port 10100M Desktop Switch with 8 Port PoE

the best Desktop Switch

Tenda POE Switches :

Tenda’s range of Power over Ethernet (PoE) adapters provide an efficient solution

Cost-effective for business and corporate networking requirements.

These switches use PoE technology, which allows both power and data to be transmitted

over a single Ethernet connection, making network device management easier and more cost-effective.

Tenda PoE switches provide fast performance and compatibility for Gigabit Ethernet rates.

Moreover, it is energy efficient, which helps save energy and reduce operating costs.

The switches are built to last, with solid metal casings

They can Withstand accidental damage and provide long-lasting functionality.

Due to its compact size and User-friendly Interface, these Switches are easy to set up and install.

Moreover, they have Quality of Service (QoS) support, which allows for better control over network traffic.

This function Prioritizes network traffic based on user Requirements.

TEF1110P 8 63W 10 Port 10100M Desktop Switch with 8 Port PoE

the best Desktop Switch

You can also check out the latest version of POE from Tenda

Specification: Tenda TEF1110P-8-63W Desktop Switch

Brand

Tenda

Model

TEF1110P-8-63W

Network standards

IEEE 802.3/3u/3x, IEEE 802.3af/at

LED Indicator

10* Link/Ack LED indicators
1 * Power LED indicator

Interfaces

8 * 10/100 Base-TX Ethernet ports (Data/Power)
2 * 10/100 Base-TX Ethernet ports (Data)

Transmission media

Recommended: CAT5/5e UTP or better

Dimension

177.5mmx104.0mmx26.0mm

Level of protection

Lightning protection for ports: 6KV
Lightning protection for power: 4KV
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV

Forwarding mode

Store-and-forward

Switch capacity

1.6 Gbps

Packet forwarding rate

1.48Mpps

Buffer

448K

MAC address table

1K

PoE budget

Single port: AF: 15.4W, AT: 30W
Whole device: 58W

Input voltage

100-240V AC 50/60Hz
51V /1.25A DC(Power Adapter )

Mounting

Desktop mounting: support
Wall mounting: support
Rack mounting:non-support

Environment

Operating Temperature: 0℃~45℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Certification

FCC、CE、RoHS

Funtions

Default Mode: If Default mode is enabled, the device works as a general switch and all ports support 10/100Mbps auto-negotiation.
Extend Mode:VLAN isolation is enabled. Port 1-8 will be isolated respectively (10/100Mbps auto-negotiation), but can communicate with the Uplink port. And the delivery distance of powering and network data is up to 250m (10Mbps)
